Neutrik NL4MMX - Adapter Speakon 2/4-pole to Speakon 2/4-pole

NL4MMX Lockable 4-pole speakon adapter

Links two NL2/4FX together for cable extension. Changes gender to male when permanently locked on the cable.

Features permanent secure connection on a speakON cable connector using 2nd lock. Can be permanently attached to NL2/4FX

Electrical
Contact resistance     ≤ 3 mΩ (after lifetime)
Dielectric strength     4 kVdc (peak)
Insulation resistance     > 1 GΩ (after dampheat)
Rated current per contact     15 A rms continuous
Rated current per contact     30 A audiosignal, duty cycle 50 %
Rated voltage     250 V (Insulation)
Attention     speakON is NOT to be used as an AC mains or power supply connector!
Mechanical
Lifetime     > 5000 mating cycles
Wiresize
Locking device     Quick Lock
Material
Contact plating     4 µm Ag
Contacts     Bronze (CuSn6)
Insert     Polyamide (PA 6 30 % GR)
Shell     Polyamide (PA 6 30 % GR)
