17250 S Butterfly Latch Large with Spring non Cranked 14mm Deep

17250S Butterfly Latch Large with Spring non Cranked 14mm Deep

The closing mechanism of the butterfly is equipped with a counter pressure spring to be automatically guided out at its opening position of approx. 30º. If additional requirements arise, the closing hook can also be moved further out.

Product type: Catches
Type: Butterfly Latches
Material: Steel
Surface: galvanized
Mounting hole diameter: 5.1 mm
Lockable: no
Dish type: non-cranked
Dish size: large
Dish depth: 14 mm
Rivet protection design: no
With push-out spring: Yes
Weight: 0,46 kg
